Question 1 |

Suppose we want to design a synchronous circuit that processes a string of 0's and 1's. Given a string, it produces another string by replacing the first 1 in any subsequence of consecutive 1's by a 0. Consider the following example.

\begin{array}{ll} \text{Input sequence:} & 00100011000011100 \\ \text{Output sequence:} & 00000001000001100 \end{array}

A Mealy Machine is a state machine where both the next state and the output are functions of the present state and the current input.

The above mentioned circuit can be designed as a two-state Mealy machine. The states in the Mealy machine can be represented using Boolean values 0 and 1. We denote the current state, the next state, the next incoming bit, and the output bit of the Mealy machine by the variables s, t, b and y respectively.

Assume the initial state of the Mealy machine is 0.

What are the Boolean expressions corresponding to t and y in terms of s and b?

\begin{array}{ll} \text{Input sequence:} & 00100011000011100 \\ \text{Output sequence:} & 00000001000001100 \end{array}

A Mealy Machine is a state machine where both the next state and the output are functions of the present state and the current input.

The above mentioned circuit can be designed as a two-state Mealy machine. The states in the Mealy machine can be represented using Boolean values 0 and 1. We denote the current state, the next state, the next incoming bit, and the output bit of the Mealy machine by the variables s, t, b and y respectively.

Assume the initial state of the Mealy machine is 0.

What are the Boolean expressions corresponding to t and y in terms of s and b?

t=s+b y=sb | |

t=b y=sb | |

t=b y=s\bar{b} | |

t=s+b y=s\bar{b} |

Question 1 Explanation:

Question 2 |

Consider the following deterministic finite automaton (DFA)

The number of strings of length 8 accepted by the above automaton is _________

The number of strings of length 8 accepted by the above automaton is _________

32 | |

256 | |

64 | |

512 |

Question 2 Explanation:

Question 3 |

Consider the following language:

L= \{ w \in \{0,1\}^* \mid w \text{ ends with the substring } 011 \}

Which one of the following deterministic finite automata accepts L?

L= \{ w \in \{0,1\}^* \mid w \text{ ends with the substring } 011 \}

Which one of the following deterministic finite automata accepts L?

A | |

B | |

C | |

D |

Question 3 Explanation:

Question 4 |

Minimum number of states required in DFA accepting binary strings not ending in "101" is

3 | |

4 | |

5 | |

6 |

Question 4 Explanation:

Question 5 |

Consider the following language.

L={x \in \{a,b\}^*| number of a's in x divisible by 2 but not divisible by 3}

The minimum number of states in DFA that accepts L is _______

L={x \in \{a,b\}^*| number of a's in x divisible by 2 but not divisible by 3}

The minimum number of states in DFA that accepts L is _______

4 | |

5 | |

6 | |

7 |

Question 5 Explanation:

Question 6 |

Let \Sigma be the set of all bijections from {1,...,5} to {1,...,5}, where id denotes the identity function, i.e. id(j)=j,\forall j. Let \circ denote composition on functions. For a string x = x_1x_2 ... x_n \in \Sigma ^n, n \geq 0, let \pi(x) = x_1\circ x_2\circ ... \circ x_n. Consider the language L = \{x \in \Sigma ^* | \pi(x) = id\}. The minimum number of states in any DFA accepting L is _________ .

25 | |

125 | |

120 | |

150 |

Question 6 Explanation:

Question 7 |

The FSM (Finite State Machine) machine pictured in the figure above

Complements a given bit pattern | |

Finds 2^{\prime} s complement of a given bit pattern | |

Increments a given bit pattern by 1 | |

Changes the sign bit |

Question 7 Explanation:

Question 8 |

Given a language L, define L^{i} as follows:

L^{0}=\{\varepsilon \}

L^{i}=L^{i-1} \cdot L for all i \gt 0

The order of a language L is defined as the smallest k such that L^{k}=L^{k+1}. Consider the language L1 (over alphabet 0) accepted by the following automaton.

The order of L1 is ______

L^{0}=\{\varepsilon \}

L^{i}=L^{i-1} \cdot L for all i \gt 0

The order of a language L is defined as the smallest k such that L^{k}=L^{k+1}. Consider the language L1 (over alphabet 0) accepted by the following automaton.

The order of L1 is ______

1 | |

2 | |

3 | |

4 |

Question 8 Explanation:

Question 9 |

Let N be an NFA with n states. Let k be the number of states of a minimal DFA which is equivalent to N. Which one of the following is necessarily true?

k\geqslant 2^{n} | |

k\geqslant n | |

k\leqslant n^{2} | |

k\leqslant 2^{n} |

Question 9 Explanation:

Question 10 |

Let \delta denote that transition function and \hat{\delta} denote the extended transition function of the \epsilon- NFA whose transition table is given below:

Then \hat{\delta}(q_{2},aba) is ____

Then \hat{\delta}(q_{2},aba) is ____

\varnothing | |

\{q_{0},q_{1},q_{3}\} | |

\{q_{0},q_{1},q_{2}\} | |

\{q_{0},q_{2},q_{3}\} |

Question 10 Explanation:

There are 10 questions to complete.
